Vacuum freeze dryer

Product name：Vacuum freeze dryer

Details：

Freeze dryer
1. Description
Vacuum freeze dryer is currently the most advance dehydrating processing technology in the world,the freeze dried food will not only can keep original shape,taste and fresh but also can be stored for a long time and easy transportation.It is widely used in the field of vegetables, fruits, spices, aquatic products, biological products, medicines, Chinese herbal medicine, beverage, and chemical etc.
We have Vacuum freeze dryer from 0.5㎡-200㎡ which can be customized according to customer needs of production.
2. Technical specification
No.	Type	Drying area(m2)	Working temperature of tray（℃）	Condensator's temperature（℃）	Water-catching weight	Power
1	ZG-10	0.5	-30~60	-50~-60	7	15
2	HTD-1	1	-30~60	-50~-60	12	18
3	HTD-2	2	-30~60	-50~-60	25	22
4	HTD-3	3	-30~60	-50~-60	40	25
5	HTD-5	5	-30~60	-50~-60	60	28
7	HTD-10	10	-30~60	-50~-60	120	40
9	HTD-15	15	-35~60	-50~-60	200	50
10	HTD-20	20	-35~60	-50~-60	250	60
11	HTD-25	25	-35~60	-50~-60	300	70
12	HTD-30	30	-35~60	-50~-60	350	90
13	HTD-35	35	-35~60	-50~-60	400	110
14	HTD-40	40	-35~60	-50~-60	550	130
15	HTD-50	50	-35~60	-50~-60	700	150
15	HTD-100	100	-35~60	-50~-60	2200	235
15	HTD-200	200	-35~60	-50~-60	3000	385
